Ciao ragazzi! Innanzitutto piacere: sono Andrea .
Ho attivato, qualche giorno fa, una linea in FTTC con WindTre (Absolute 200 Mb), utilizzando un modem già in mio possesso (uno Zyxel, tra l'altro, fornito da loro qualche tempo fa per un'altra utenza).
I valori sono discreti, ma secondo me non buonissimi, anche perché riscontro un problema non indifferente: ho l'upload piuttosto lento! Con Speedtest, ad esempio, non riesco mai a superare i 4Mb .
Ho una presa tripolare classica (unica presa di casa, essendo un monolocale), a cui ho collegato un adattatore tripolare-rj11 (fornito dall'allora Infostrada, assieme al router di cui sopra). Il problema ce l'ho sia collegando direttamente l'RJ11 dal modem a questo adattatore, sia inserendo un filtro VDSL-TEL di Telecom (probabilmente, non serve neanche?).
Nei giorni scorsi, tra l'altro, mi è capitato di avere anche una o due disconnessioni, nonostante, comunque, la linea sembri stabile.
Ecco i valori:
============================================================================
VDSL Training Status: Showtime
Mode: VDSL2 Annex B
VDSL Profile: Profile BrcmPriv1
Traffic Type: PTM Mode
Link Uptime: 0 day: 0 hour: 24 minutes
============================================================================
VDSL Port Details Upstream Downstream
Line Rate: 21.599 Mbps 110.391 Mbps
Actual Net Data Rate: 21.600 Mbps 110.392 Mbps
Trellis Coding: ON ON
SNR Margin: 9.1 dB 5.9 dB
Actual Delay: 0 ms 0 ms
Transmit Power: -21.7 dBm 14.5 dBm
Receive Power: -27.6 dBm 3.7 dBm
Actual INP: 59.0 symbols 57.0 symbols
Total Attenuation: 5.9 dB 10.7 dB
Attainable Net Data Rate: 29.823 Mbps 109.735 Mbps
============================================================================
VDSL Band Status U0 U1 U2 U3 D1 D2 D3
Line Attenuation(dB): 1.1 7.3 11.7 13.3 4.5 10.1 22.1
Signal Attenuation(dB): 1.1 6.7 10.3 12.7 5.7 10.0 21.2
SNR Margin(dB): 9.2 9.1 9.2 9.1 5.9 5.9 5.9
Transmit Power(dBm):-31.2 -23.2 -29.4 -37.2 7.8 7.9 12.0
============================================================================
VDSL Counters
Downstream Upstream
Since Link time = 24 min 23 sec
FEC: 36 15
CRC: 0 0
ES: 0 0
SES: 0 0
UAS: 0 0
LOS: 0 0
LOF: 0 0
LOM: 0 0
Retr: 0
HostInitRetr: 0
FailedRetr: 0
Latest 15 minutes time = 9 min 30 sec
FEC: 0 15
CRC: 0 0
ES: 0 0
SES: 0 0
UAS: 0 0
LOS: 0 0
LOF: 0 0
LOM: 0 0
Retr: 0
HostInitRetr: 0
FailedRetr: 0
Previous 15 minutes time = 15 min 0 sec
FEC: 36 0
CRC: 0 0
ES: 0 0
SES: 0 0
UAS: 5 5
LOS: 0 0
LOF: 0 0
LOM: 0 0
Retr: N/A
HostInitRetr: N/A
FailedRetr: N/A
Latest 1 day time = 23 hours 24 min 30 sec
FEC: 9205 2547
CRC: 559 0
ES: 11 0
SES: 11 0
UAS: 62 51
LOS: 1 0
LOF: 1 0
LOM: 0 0
Retr: 1
HostInitRetr: 0
FailedRetr: 0
Previous 1 day time = 24 hours 0 sec
FEC: 4609710 2735
CRC: 3776 0
ES: 68 0
SES: 67 0
UAS: 146 79
LOS: 2 0
LOF: 1 0
LOM: 8 0
Retr: 2
HostInitRetr: 0
FailedRetr: 0
Total time = 1 days 23 hours 24 min 30 sec
FEC: 4687333 22439
CRC: 4335 0
ES: 79 0
SES: 78 0
UAS: 252 174
LOS: 3 0
LOF: 2 0
LOM: 8 0
Retr: 3
HostInitRetr: 0
FailedRetr: 0
============================================================================
Grazie anticipatamente a tutti per l'aiuto.
EDIT: ecco anche uno speedtest appena effettuato:
